神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINES - K907D & K907LC EXCAVATORS (1/86-12/06) (03-010) - AUTOMATIC TIMER (INNER PARTS) (PN 3186081040) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-9. | VA3186081040 | [1] | TIMER AUTOMATIC TIMER ASSY SCZ TYPE,FOR M0 ONLY | TIMER AUTOMATIC TIMER ASSY SCZ TYPE,FOR M0 ONLY |
| . . | VA3186081050 | [1] | TIMER ASSY SC2 TYPE,FOR M1 ONLY | TIMER ASSY SC2 TYPE,FOR M1 ONLY |
| 1. | VA9055728000 | [1] | RING,SNAP | |
| 2. | VA9490132770 | [1] | WASHER,PLATE T = 1.0 | |
| . . | VA9490132760 | [1] | WASHER,PLATE T = 0.2 | |
| 3. | VA918500130 | [1] | GEAR,DRIVE,FOR M0 ONLY | |
| . . | VA918400440 | [1] | FLANGE,DRIVING,FOR M1 ONLY | |
| . . | VA918360134 | [2] | WEIGHT,TIMER | |
| 6. | VA918190830 | [2] | SPRING,TIMER | |
| 8. | VA918100520 | [1] | HUB ASSY | |
| 9. | VA9490131480 | [1] | WASHER,PLATE T = 0.3 | |
| 9. | VA9490131490 | [1] | WASHER,PLATE T = O.1 | |
| 9. | VA9490131980 | [1] | WASHER,PLATE T = 0.5 | |
