凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (016) - IMPLEMENT DRIVELINE, 540 PTO, BONDIOLI, REFER TO PAGE 18 FOR DRIVELINE IDENTIFICATION Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
965 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707184
|
[1] |
PTO
|
HFI
Implement Half Assembly Superseded by part number: 700709855
|
| 2. |
700707185
|
[1] |
SHAFT
|
CAS
Tractor Half Assembly Superseded by part number: 87526444
|
| 3. |
700707183
|
[1] |
CHAIN (AG)
|
CAS
Chain - Safety Superseded by part number: 87586692
|
| 4. |
700707192
|
[1] |
CHAIN (AG)
|
CAS
Chain - Safety "Y" Superseded by part number: 1325192C1
|
| 5. |
700707180
|
[1] |
SHIELD
|
CAS
Tube - Shield, Outer
|
| 6. |
700707189
|
[1] |
SHIELD
|
CAS
Bearing - Shield, Outer Superseded by part number: 84036372
|
| 7. |
700707169
|
[1] |
YOKE
|
HFI
- Quick Disconnect
|
| 8. |
700707181
|
[1] |
COLLAR
|
CAS
- Yoke Superseded by part number: 9805371
|
| 9. |
700707191
|
[1] |
SHIELD
|
HFI
Cone - Shield
|
| 10. |
700707495
|
[2] |
NUT
|
CAS
Ring - Bearing
|
| 11. |
700707187
|
[5] |
NIPPLE, LUBE
|
CAS
Zerk
|
| 12. |
700707179
|
[2] |
CROSS
|
CAS
Journal Repair Kit
|
| 13. |
700707178
|
[1] |
BODY
|
HFI
- CVJ
|
| 14. |
700707177
|
[1] |
FORK
|
CAS
Yoke
|
| 15. |
763847
|
[1] |
PIN
|
CAS
- Spring
|
| 16. |
700707176
|
[1] |
TUBE
|
CAS
- Drive, Outer Superseded by part number: 700709852
|
| 17. |
700707175
|
[1] |
NUT
|
CAS
Ring - Center
|
| 18. |
700707170
|
[1] |
FORK
|
CAS
Yoke - Clamp Superseded by part number: 700709853
|
| 19. |
700707171
|
[1] |
CROSS
|
CAS
Journal Repair Kit Superseded by part number: 84004289
|
| 20. |
700707193
|
[1] |
NIPPLE, LUBE
|
CAS
Zerk Superseded by part number: 150024
|
| 21. |
700707496
|
[1] |
SCREW
|
CAS
M12 x 1.75 x 70 C
|
| 22. |
700707173
|
[1] |
TUBE
|
CAS
- Drive, Inner
|
| 23. |
700707194
|
[1] |
PIN
|
CAS
- Flexible Superseded by part number: 84036368
|
| 24. |
700707172
|
[1] |
TUBE
|
CAS
Yoke - Tube, Inner Superseded by part number: 84004288
|
| 25. |
700707186
|
[1] |
SHIELD
|
CAS
Tube - Shield, Inner
|
| 26. |
700707188
|
[1] |
INNER SHIELD
|
CAS
Bearing - Shield, Inner Superseded by part number: 84036377
|
| 27. |
700709108
|
[1] |
SHIELD
|
CAS
- Cone, Implement Superseded by part number: 84043014
|
| 28. |
700709107
|
[1] |
SHIELD
|
CAS
- Cone, Tractor
|
| 29. |
700708790
|
[1] |
KIT
|
IH
Pin - Push Superseded by part number: 782083
|
