凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (021) - GEARBOX Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
223 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700709190
|
[1] |
GEARBOX ASSY
|
CAS
Gearbox Complete - Primary
|
| 1. |
700709400
|
[2] |
SHAFT
|
CAS
Superseded by part number: 700712180, 700712179
|
| 2. |
700709192
|
[2] |
CAP
|
CAS
Assembly (With Cup and Seal)
|
| 3. |
806950
|
[1] |
GASKET
|
IH
- .003
|
| . . |
806943
|
[1] |
GASKET
|
IH
- .005
|
| . . |
806935
|
[1] |
GASKET
|
IH
- .015
|
| 4. |
800383
|
[2] |
SEAL
|
CAS
- Oil Superseded by part number: H755694
|
| 5. |
7710106
|
[2] |
DIFFERENTIAL
|
CAS
Bearing Cup Superseded by part number: 73124678
|
| 6. |
7710114
|
[2] |
BEARING
|
CAS
Cone Superseded by part number: 73124678
|
| 7. |
800334
|
[2] |
ROLLER BEARING,29.38 mm ID x 25.433 mm
|
HFI
Bearing Cone
|
| 8. |
800342
|
[2] |
BEARING CUP,66.421 mm OD x 19.05 mm
|
CAS
Cup Superseded by part number: 86900791
|
| 9. |
800359
|
[1] |
GEAR
|
CAS
|
| 10. |
700709193
|
[2] |
KEY
|
CAS
- Special
|
| 11. |
700709419
|
[2] |
WASHER
|
CAS
- Special
|
| 12. |
700709191
|
[1] |
BOX
|
CAS
Assembly (With Bearing Cup)
|
| 13. |
800243
|
[1] |
SHIM
|
CAS
- .010 Superseded by part number: 700711935
|
| . . |
800250
|
[1] |
SHIM
|
CAS
- .005 Superseded by part number: 700711936
|
| . . |
800268
|
[1] |
SHIM
|
CAS
- .002
|
| 14. |
800318
|
[1] |
GEAR
|
CAS
Superseded by part number: 700711939
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
800417
|
[16] |
SCREW
|
CAS
3/8-16 x 1-1/4 C (Sems) Grade 5
|
