凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (022) - GEARBOX, S.N. CFH0015897 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
159 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700710131
|
[1] |
TRANSFER BOX
|
IH
Gearbox Complete - Primary Superseded by part number: 700725114
|
| 1. |
700710827
|
[2] |
SEAL
|
IH
|
| 2. |
700710828
|
[2] |
OIL SEAL
|
CAS
Ring - Retaining
|
| 3. |
700710815
|
[1] |
PINION
|
CAS
Shaft - Pinion
|
| 4. |
700710817
|
[3] |
BEARING
|
CAS
- Cone, Tapered Superseded by part number: 115970
|
| 5. |
710350
|
[3] |
BRACKET,69.037 mm OD x 15.875 mm
|
CAS
- Bearing Superseded by part number: ST991
|
| 6. |
712208
|
[1] |
CUP
|
CAS
- Bearing Superseded by part number: 86516462
|
| 7. |
712166
|
[1] |
CONE
|
CAS
Bearing - Cone, Tapered Superseded by part number: 86516471
|
| 8. |
700710823
|
[1] |
GEAR
|
CAS
(20 Tooth)
|
| 9. |
700710824
|
[1] |
CASTING
|
CAS
(Thru Holes) Superseded by part number: 700725113, 700725112, 700725334
|
| 10. |
746578
|
[1] |
PLUG
|
HFI
1/4 NPT Solid Plug Superseded by part number: 9617020
|
| 11. |
746586
|
[1] |
PLUG
|
HFI
1/2 NPT Solid Plug Superseded by part number: 86642423
|
| 12. |
701367
|
[9] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 x 2-1/4 HSHCS Superseded by part number: 61-636
|
| 13. |
700710821
|
[1] |
GEAR
|
CAS
(27 Tooth) Superseded by part number: 700725114
|
| 14. |
700710820
|
[1] |
SPACER
|
CAS
|
| 15. |
700710816
|
[1] |
CROSS SHAFT
|
CAS
Shaft - Cross Superseded by part number: 700725114
|
| 16. |
700710825
|
[1] |
CASTING
|
CAS
(Tapped Holes) Superseded by part number: 700725113, 700725112, 700725334
|
| 17. |
700710819
|
[1] |
DIPSTICK
|
CAS
|
| 18. |
700710818
|
[1] |
VALVE
|
CAS
Breather
|
| 19. |
846642
|
[1] |
BUSHING
|
CAS
1/2-1/8 NDT Reducer Bushing
|
