凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (045) - DRIVE SHAFT, CLUTCH, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
558 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
Bearing Assembly
|
| 2. |
700116057
|
[1] |
SHAFT
|
IH
- Cross
|
| 3. |
6872915
|
[1] |
KEY
|
CAS
5/16 x 5/16 x 1-1/2 Key Superseded by part number: Q1443
|
| 4. |
700102113
|
[1] |
HUB
|
CAS
- Block
|
| 5. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
Bearing - Spherical Superseded by part number: 47577203
|
| 6. |
700119086
|
[1] |
PLATE
|
HFI
(S.N. CFH0015275 thru 0016101)
|
| 7. |
700126762
|
[1] |
PLATE
|
HFI
(S.N. CFH0016102 and on)
|
| . . |
7700156
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 RHSNB Superseded by part number: 280420
|
| . . |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 280486
|
| . . |
700710984
|
[4] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
1/2-13 x 1-1/4 HFS
|
