凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (044) - CLUTCH, SLIP, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
164 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709603
|
[6] |
WASHER,3/8"
|
CAS
3/8 Wide Plain Washer Superseded by part number: 80702
|
| 2. |
58107
|
[6] |
SPRING
|
IH
- Compression
|
| 3. |
6248173
|
[1] |
LARGE PLATE
|
IH
Plate - Pressure
|
| 4. |
51200260
|
[1] |
DISC
|
CAS
- Center
|
| 5. |
700710945
|
[2] |
CLUTCH PLATE,126.75mm ID x 203.2mm OD x 3.18mm Thk
|
L
Disc - Fiber
|
| 6. |
805580
|
[1] |
BRONZE BUSHING
|
IH
Bushing - Bronze
|
| 7. |
704056
|
[1] |
NUT
|
CAS
1/2-13 Hex Jam Nut Superseded by part number: 86632558
|
| 8. |
700102115
|
[1] |
HUB
|
CAS
Assembly (Includes Bushing) Superseded by part number: 700125029, 86570628
|
| . . |
7770498
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3 1/4", Gr 5
|
CAS
3/8-16 x 3-1/4 RHSNB Superseded by part number: 27454R1
|
| . . |
74781
|
[6] |
NUT
|
CAS
3/8-16 LHSN Superseded by part number: 231-1406, 231-1406, NS
|
