凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (026) - PICKUP, TINE, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
660 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108622
|
[8] |
FLANGED BEARING
|
L
Flange - Bearing
|
| 2. |
700114147
|
[1] |
ROTOR
|
HFI
Shaft - Rotor
|
| 3. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
Bearing - Spherical Superseded by part number: 84330047
|
| 4. |
700108618
|
[4] |
ARM
|
L
Crank - Tine Bar
|
| 5. |
700705612
|
[4] |
CAM FOLLOWER
|
L
Bearing - Cam Superseded by part number: 86536275
|
| 6. |
702700045
|
[4] |
LOCK NUT
|
L
- Spiralock
|
| 7. |
700707143
|
[36] |
TINE
|
CAS
- Double (S.N. CFH0015001 thru 0015766) Mating Part (Diameter) for the 700114154 Bar. Superseded by part number: 700709760, 86521609
|
| 7. |
700709760
|
[36] |
TINE
|
L
Tine - Double (S.N. CFH0015767 and on) Mating Part (Diameter) for the 700120390 Bar
|
| 8. |
700114154
|
[4] |
ANGLE
|
CAS
Bar - Tine (S.N. CFH0015001 thru 0015766) Sub 700120390 Bar, 700709760 Tine (9) and 3/8-16 HFTLN (9) Superseded by part number: 700709760, 86521609, 700120390
|
| 8. |
700120390
|
[1] |
ANGLE BAR
|
IH
Bar - Tine (S.N. CFH0015767 and on) 700709760 Tines are Mating Parts
|
| 9. |
701367
|
[4] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 x 2-1/4 HSHCS Superseded by part number: 61-636
|
| . . |
7700065
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
700047
|
[36] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
704734
|
[40] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
