| 1. |
700122837
|
[1] |
TOOTH
|
IH
Wrapper - Tine, Left
|
| 2. |
700114144
|
[15] |
GUARD
|
L
Wrapper - Tine, Center
|
| 3. |
700122840
|
[1] |
TOOTH
|
IH
Wrapper - Tine, Right
|
| 4. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 5. |
700114134
|
[1] |
DEFLECTOR
|
HFI
- Right
|
| 6. |
700114118
|
[1] |
FRAME
|
HFI
- Pickup
|
| 7. |
700114172
|
[1] |
TUBE,38.1 mm OD, 102 mm Length
|
CAS
- Pivot, Pickup
|
| 8. |
700709607
|
[1] |
WASHER,3/4"
|
CAS
3/4 Wide Plain Washer Superseded by part number: 86511191
|
| 9. |
700116125
|
[1] |
HOUSING
|
CAS
Camtrack
|
| 10. |
51417
|
[2] |
PIPE
|
IH
- Bearing Superseded by part number: 617863R1, 617863R1, NLS
|
| 11. |
700709621
|
[1] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
- Spherical, Hex Bore Superseded by part number: 47442495
|
| 12. |
700709606
|
[1] |
WASHER,5/8"
|
CAS
5/8 Wide Plain Washer Superseded by part number: 80299
|
| 13. |
378521
|
[1] |
SPACER
|
CAS
Bushing
|
| 14. |
700114170
|
[1] |
STRAP
|
HFI
- Link, Pickup
|
| . . |
703249
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
702035
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7701758
|
[1] |
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 5
|
CAS
5/8-11 x 1-1/2 C Superseded by part number: 88062
|
| . . |
7883002
|
[1] |
BOLT,Hex 3/4" - 10 x 5 1/2", Gr 5
|
CAS
3/4-10 x 5-1/2 C Superseded by part number: 86507002
|
| . . |
700013
|
[18] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7703440
|
[17] |
BOLT,Hex Flange, 5/16" - 18 x 5/8"
|
CAS
5/16-18 x 5/8 HFSS Superseded by part number: 271288
|
| . . |
703132
|
[1] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
