凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (032) - PICKUP LIFT ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
793 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200240
|
[2] |
BUSHING
|
CAS
|
| 2. |
700114185
|
[1] |
CRANK
|
CAS
Bellcrank - Left
|
| 3. |
77032
|
[2] |
FITTING
|
CAS
1/4-28 Zerk Superseded by part number: 88775
|
| 4. |
700114196
|
[2] |
STEM
|
IH
Rod - Link
|
| 5. |
066183
|
[4] |
CLEVIS
|
IH
- 1/2-13 Thread Superseded by part number: 70937465
|
| 6. |
700114176
|
[1] |
TUBE
|
CAS
Tub Assembly - Torque
|
| 7. |
63966
|
[1] |
PIN
|
CAS
1/2 x 2 Clevis Pin
|
| 8. |
700114190
|
[1] |
CLEVIS
|
HFI
|
| 9. |
77057
|
[1] |
|
IH
1/4-28 x 90 Degree Zerk Superseded by part number: 87415, 87415, NLS
|
| 10. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 Hardened Plain Washer
|
| 11. |
700707873
|
[1] |
THRUST BEARING
|
IH
Bearing - Thrust Superseded by part number: 700722820
|
| 12. |
6292387
|
[1] |
SPACER,31.75 mm OD, 44.5 mm Length
|
CAS
|
| 13. |
700114193
|
[1] |
CRANK
|
CAS
Arm - Crank
|
| 14. |
700114197
|
[1] |
TUBE,21 mm ID, 25.4 mm OD, 72 mm Length
|
CAS
- Crank
|
| 15. |
73205
|
[1] |
SCREW
|
CAS
1/2-13 x 3-1/2 HSHCS Superseded by part number: 9406829, 9406829, NLS
|
| 16. |
702019
|
[1] |
SCREW
|
CAS
3/8-16 x 4 HSHCS Superseded by part number: 61-33864
|
| 17. |
700114183
|
[1] |
LEVER
|
CAS
Arm - Torque, End
|
| 18. |
6869382
|
[1] |
SPACER
|
HFI
|
| 19. |
63677
|
[3] |
WASHER
|
IH
1/2 x 1-27/64 Clevis Pin Superseded by part number: 2975160, 2975160, IH63677
|
| 20. |
52258
|
[2] |
BUSHING
|
CAS
1 x 14 Gauge Machinery Bushing
|
| 21. |
700114186
|
[1] |
CRANK
|
CAS
Bellcrank - Right
|
| 22. |
700709605
|
[2] |
WASHER,1/2"
|
CAS
1/2 Wide Plain Washer Superseded by part number: 80700
|
| . . |
7701188
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
