| 1. |
704155
|
[2] |
NUT
|
CAS
5/8-11 Hex Jam Nut Superseded by part number: 86632556
|
| 2. |
700114164
|
[1] |
SHIELD
|
HFI
- Chain
|
| 3. |
38-32436
|
[1] |
PIN,3/8" x 2 1/4", Coiled
|
WIC
3/8" x 2 1/4", Coiled Superseded by part number: 87610718
|
| 4. |
52712
|
[1] |
BUSHING
|
CAS
1-1/2 x 18 Gauge Machinery Bushing
|
| 5. |
NLS
|
[7] |
NO LONGER SERVICED
|
BAS
1-1/2 x 14 Gauge Machinery Bushing
|
| 6. |
700117122
|
[1] |
SPROCKET ASSY.
|
CAS
Sprocket - 50-P, 35-Tooth
|
| 7. |
395871
|
[1] |
SPACER
|
CAS
|
| 8. |
700114133
|
[1] |
DEFLECTOR
|
HFI
- Left
|
| 9. |
700114174
|
[1] |
SPACER
|
CAS
|
| 10. |
740712
|
[1] |
OIL SEAL
|
CAS
Snap Ring Superseded by part number: 66967
|
| 11. |
712604
|
[2] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Bearing - Cylindrical Superseded by part number: 87029275
|
| 12. |
700114166
|
[1] |
PULLEY
|
IH
Sheave and Sprocket Assembly
|
| 13. |
700114171
|
[1] |
TUBE,38.1 mm OD, 135.5 mm Length
|
CAS
Bushing - Pivot
|
| 14. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
- Bearing
|
| 15. |
713834
|
[1] |
BUSHING
|
NNA
- Spherical, Hex Bore Superseded by part number: 700709621
|
| 16. |
6610844
|
[1] |
SPACER
|
CAS
|
| 17. |
700114170
|
[1] |
STRAP
|
HFI
- Link, Pickup
|
| 18. |
378521
|
[1] |
SPACER
|
CAS
Bushing
|
| 19. |
700709606
|
[2] |
WASHER,5/8"
|
CAS
5/8 Wide Plain Washer Superseded by part number: 80299
|
| 20. |
6156871
|
[1] |
SPACER
|
CAS
|
| 21. |
87973
|
[2] |
GROOVED PIN
|
NNA
Sprocket - Idler, 50-P, 17-Tooth Superseded by part number: 211623C91, 211623C91, 50598
|
| 22. |
700114929
|
[2] |
TUBE,31.75 mm OD, 41 mm Length
|
CAS
Spacer
|
| 23. |
705582
|
[3] |
WASHER
|
CAS
5/8 Hardened Plain Washer Superseded by part number: 396-21066, 396-21066, NLS
|
| . . |
703934
|
[1] |
BOLT,Hex, 5/8" - 11 x 5 1/2", Gr 5
|
CAS
5/8-11 x 5-1/2 C Superseded by part number: 280232, 280232, 87791065
|
| . . |
7883069
|
[1] |
HARDWARE
|
HFI
3/4-10 x 8C Superseded by part number: 414-12128
|
| . . |
700013
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
7870603
|
[1] |
BOLT,Sq Nk, 5/8" - 11 x 5 1/2", Gr 5
|
CAS
5/8-11 x 5-1/2 RHSNB
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
703132
|
[1] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
