凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (038) - CONTROL BOX AND CABLE ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
755 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707818
|
[2] |
RING
|
CAS
Kit - Coupling Superseded by part number: 60-6127T2
|
| 2. |
700707360
|
[1] |
CABLE
|
CAS
- Electrical
|
| 3. |
8799264
|
[1] |
SWITCH
|
CAS
- 2 Position Superseded by part number: 700126398
|
| 3. |
700126398
|
[1] |
KIT
|
CAS
Switch Kit - Service Parts Includes Items 4, 21, and 22
|
| 4. |
702700050
|
[1] |
FUSE
|
IH
(5 Amp) Superseded by part number: 86705048
|
| 5. |
700707758
|
[1] |
CONTAINER
|
CAS
Receptacle - Electrical, 9 Pin
|
| 6. |
700707757
|
[1] |
CONTAINER
|
CAS
Receptacle - Electrical, 4 Pin
|
| 7. |
700707598
|
[1] |
WIRE HARNESS
|
IH
Cable - Electrical
|
| 8. |
700707759
|
[1] |
INDICATOR
|
IH
Lamp - Pilot
|
| 9. |
700707458
|
[1] |
INDICATOR
|
IH
Light - Indicator, Green
|
| 10. |
700707459
|
[1] |
INDICATOR
|
IH
Light - Indicator, Amber
|
| 11. |
701607
|
[6] |
BRACKET
|
CAS
1/4-20 x 1/2 HWHTCTS Superseded by part number: 281-1478, 281-1478, NLS
|
| 12. |
700116147
|
[1] |
COVER
|
HFI
- Control
|
| 13. |
700707771
|
[1] |
DECAL
|
CAS
- Control Box
|
| 14. |
A59457
|
[1] |
BRACKET
|
CAS
Socket - Bracket Superseded by part number: 847590
|
| 15. |
6866081
|
[1] |
BRACKET
|
CAS
Spade - Socket
|
| 16. |
700703984
|
[1] |
INDICATOR
|
IH
- Audio
|
| 17. |
700116059
|
[1] |
TERMINAL BOX
|
CAS
Control Box Assembly Complete
|
| 18. |
700707817
|
[1] |
RING
|
CAS
Kit - Coupling Superseded by part number: 225426C1
|
| 19. |
700710307
|
[1] |
BULB
|
IH
- 12 V
|
| 20. |
700709553
|
[1] |
RESISTOR
|
IH
(Used with all Bale Ejector Kickers)
|
| 21. |
700711048
|
[1] |
IGNITION SWITCH
|
IH
Switch
|
| 22. |
700711019
|
[1] |
HARNESS
|
CAS
Wire - Electrical
|
| . . |
703066
|
[2] |
SCREW
|
HFI
5/16-18 x 3/4 HWHMS
|
