凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (040) - ELECTRICAL SENSOR AND ACTUATOR ASSEMBLY, SERIAL NUMBER CFH0015001 THROUGH 0015274 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
858 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
751487
|
[9] |
CLAMP
|
CAS
Superseded by part number: 86632595
|
| 2. |
722470
|
[1] |
MOUNTING CLIP
|
CAS
Tie - Nylon Superseded by part number: 529070
|
| 3. |
700707362
|
[1] |
HARNESS
|
HFI
- Wiring
|
| 4. |
700707353
|
[3] |
SENSOR
|
CAS
|
| 5. |
700707354
|
[2] |
CONNECTION,ELECTRIC
|
IH
Actuator
|
| 6. |
700116136
|
[1] |
SUPPORT
|
HFI
- Switch
|
| 7. |
701953
|
[2] |
SELF-TAP SCREW
|
CAS
5/16-18 x 3/4 HWHTCTS Superseded by part number: 172463
|
| 8. |
705657
|
[6] |
WASHER
|
CAS
3/8 Narrow Plain Washer Superseded by part number: 495-11041, 495-11041, NLS
|
| . . |
7883325
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883382
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
