纽荷兰零件查询(ISM N844) - ISM ENGINE (10.101.02[01]) - CYLINDER HEAD COVER & CRANKSHAFT PULLEY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
766 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | SBA111996401 | [1] | GASKET | DUB |
| 2. | SBA111217620 | [1] | COVER | WIC Superseded by part number: SBA111211440 |
| 3. | SBA110666210 | [1] | COVER | DUBOil |
| 4. | SBA110666060 | [1] | FILTER SCREEN | NH |
| 5. | SBA015600406 | [6] | SCREW | DUB |
| 6. | SBA140996270 | [4] | SEAL | NH |
| 7. | SBA024600010 | [4] | NUT | NHCap |
| 8. | SBA110566080 | [1] | BREATHER | DUB |
| 9. | SBA011100408 | [4] | BOLT | DUB |
| 10. | SBA052100400 | [2] | O-RING,3.5mm Thk x 39.7mm ID, 70 Duro | NH |
| 11. | SBA110466031 | [1] | TUBE | SBA |
| 13. | SBA198436010 | [1] | FILLER CAP | NH |
| 14. | SBA011310640 | [2] | CAPTIVE WASHER SCREW,Hex, M6 x 40, Cl 8.8 | DUB |
| 15. | SBA011310660 | [3] | BOLT | NH |
| 16. | SBA135996950 | [1] | MANIFOLD GASKET | DUB Superseded by part number: SBA135996951 |
| 17. | SBA135566470 | [1] | AIR INTAKE TUBE | WIC |
| 18. | SBA011300625 | [2] | BOLT | SBA Superseded by part number: SBA011310625 |
| 19. | SBA115396860 | [1] | PULLEY | SBACrankshaft |
| 20. | SBA020109086 | [1] | NUT | NH |
| 21. | 86511328 | [1] | WASHER,25mm ID x 44mm OD x 4mm Thk | NH |
