纽荷兰零件查询(ISM N844) - ISM ENGINE (10.102.01) - OIL PAN & GAUGE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
171 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | SBA110708030 | [1] | ENGINE OIL PAN | SBA |
| 2. | SBA010109235 | [30] | BOLT | NH |
| 3. | SBA010411212 | [2] | DRAIN PLUG,M12 x 1.25 | NH |
| 4. | SBA025100012 | [2] | WASHER,12.4mm ID x 19mm OD x 2mm Thk | NHSeal |
| 5. | SBA110756371 | [1] | TUBE | SBAGauge, Complete |
| 6. | SBA052100100 | [2] | O-RING | NH |
| 7. | SBA011310612 | [1] | CAPTIVE WASHER SCREW,Hex, M6 x 12, Cl 8.8 | NH Superseded by part number: SBA010700610 |
| 8. | SBA198416570 | [1] | DIPSTICK | SBAComplete |
| 9. | SBA011510812 | [1] | CAPTIVE WASHER SCREW,Hex, M8 x 12, G5 | NH |
