沃尔沃零件查询2001; 2001B; 2001AG; 2001BG; 2002; 2002B; 2002D; 2002AG; 2002BG; 2003; 2003B; 2003D; 2003AG; 2003BG; 2003T; 2003TB; 2003 SOLAS; 2003B SOLAS; 2003TMiscellaneous EquipmentFresh-water Cooling and Hot Water OutletEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
467 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
840770
|
[1] |
Heat exchanger kit
|
|
| 2. |
860358
|
[1] |
Circulation pump
|
(840710)
|
| 3. |
|
|
|
|
| 4. |
|
|
|
|
| 5. |
840711
|
[1] |
Bracket
|
|
| 6. |
|
|
|
|
| 7. |
955276
|
[3] |
Hexagon screw
|
L=35mm
|
| 8. |
949246
|
[1] |
Plug
|
|
| 9. |
|
|
|
Included in repair kit 876270 for circulation pump 840710 and 860358.
|
| 10. |
840795
|
[1] |
Gasket
|
Included in repair kit 876270 for circulation pump 840710 and 860358.
|
| 11. |
|
|
|
Included in repair kit 876270 for circulation pump 840710 and 860358.
|
| 12. |
|
|
|
Included in repair kit 876270 for circulation pump 840710 and 860358.
|
| 13. |
418411
|
[3] |
Sealing ring
|
Included in repair kit 876270 for circulation pump 840710 and 860358.
|
| 14. |
966906
|
[1] |
V-belt
|
(958306)
|
| 15. |
955305
|
[1] |
Hexagon screw
|
L=75mm
|
| 16. |
418445
|
[1] |
Sealing ring
|
|
| 17. |
840737
|
[1] |
Coolant pipe
|
|
| 18. |
840907
|
[1] |
Hose connection
|
|
| 19. |
418411
|
[1] |
Sealing ring
|
|
| 20. |
840739
|
[1] |
Tube
|
|
| 21. |
418411
|
[1] |
Sealing ring
|
|
| 22. |
840729
|
[1] |
Coolant pipe
|
|
| 23. |
840741
|
[1] |
Heat exchanger
|
Replaced by heat exchanger 859360 and mounting kit 859387
|
| 24. |
|
|
|
|
| 25. |
829972
|
[1] |
Gasket
|
|
| 26. |
829988
|
[1] |
End plate
|
|
| 27. |
829989
|
[1] |
Gasket
|
|
| 28. |
840745
|
[1] |
End plate
|
|
| 29. |
829991
|
[1] |
Bar
|
|
| 30. |
840746
|
[1] |
Cap
|
|
| 31. |
941906
|
[2] |
Spring washer
|
|
| 32. |
963105
|
[2] |
Lock nut
|
|
| 33. |
191026
|
[1] |
Plug
|
|
| 34. |
829714
|
[1] |
Sealing ring
|
|
| 35. |
840724
|
[1] |
Coolant pipe
|
|
| 36. |
843075
|
[2] |
Spacer sleeve
|
|
| 37. |
955297
|
[2] |
Hexagon screw
|
|
| 38. |
418411
|
[2] |
Sealing ring
|
|
| 39. |
840731
|
[1] |
Coolant pipe
|
|
| 40. |
829714
|
[1] |
Sealing ring
|
|
| 41. |
418445
|
[1] |
Sealing ring
|
|
| 42. |
840735
|
[1] |
Coolant pipe
|
MD2002
|
| 42. |
840736
|
[1] |
Coolant pipe
|
MD2003
|
| 43. |
875795
|
[1] |
Thermostat kit
|
74°C
|
| 44. |
416033
|
[1] |
Sealing ring
|
|
| 45. |
418445
|
[1] |
Sealing ring
|
|
| 46. |
840797
|
[2] |
Plug
|
|
| 47. |
943194
|
[2] |
Washer
|
|
| 48. |
840676
|
[1] |
Clamp
|
|
| 49. |
3547466
|
[1] |
Expansion tank
|
|
| 50. |
844624
|
[1] |
Pressure cap
|
|
| 51. |
961666
|
[2] |
Hose clamp
|
|
| 52. |
943369
|
[1] |
Rubber hose
|
Hose lenght refers to bulk head mounted expansion tank., L=1700mm
|
| 53. |
840712
|
[1] |
Bracket
|
|
| 54. |
858295
|
[1] |
Anchorage
|
(840888)
|
| 55. |
840828
|
[1] |
Clamp
|
|
| 56. |
955269
|
[1] |
Hexagon screw
|
|
| 57. |
965622
|
[1] |
Square neck screw
|
|
| 58. |
955306
|
[2] |
Hexagon screw
|
|
| 59. |
833243
|
[1] |
Spacer sleeve
|
|
| 60. |
955894
|
[1] |
Washer
|
|
| 61. |
961662
|
[2] |
Hose clamp
|
|
| 62. |
942700
|
[1] |
Hose
|
Hose lenght refers to bulk head mounted expansion tank., L=1500mm
|
| 63. |
858185
|
[1] |
Hose coupling
|
(829917)
|
| 64. |
858523
|
[1] |
Kit
|
|
| 65. |
961653
|
[1] |
Hose nipple
|
|
| 66. |
479978
|
[1] |
Nipple
|
|
| 67. |
859387
|
[1] |
Mounting kit
|
|
| 68. |
859363
|
[1] |
Bracket
|
|
| 69. |
859095
|
[1] |
Bracket
|
|
| 70. |
946173
|
[4] |
Flange screw
|
|
| 71. |
945408
|
[2] |
Flange nut
|
|
| 71. |
|
|
|
|
| 71. |
876270
|
[1] |
Repair kit, circ. pump
|
(876152)
|
