凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (100) - HYDRAULIC, CROSS LINES, ASSEMBLY, SERIAL NUMBER CFH0015275 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
648 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700116034
|
[2] |
CLAMP
|
HFI
- Line
|
| 2. |
738468
|
[3] |
O-RING
|
IH
|
| 3. |
8046658
|
[3] |
TEE
|
CAS
- Straight Run (Includes O-Ring) Superseded by part number: 86513020
|
| 4. |
700708717
|
[1] |
TUBE,12.7 mm OD, 856 mm Length
|
CAS
Line - Hydraulic
|
| 5. |
8042715
|
[2] |
HYDRAULIC HOSE,9.65 mm ID x 787.00 mm, SAE 100R1,SAE J517,SAE J343,SAE J516
|
CAS
9.65 mm ID x 787.00 mm, SAE 100R1,SAE J517,SAE J343,SAE J516
|
| 6. |
7046626
|
[2] |
ELBOW
|
CAS
90 Degree Elbow Superseded by part number: 216791
|
| 7. |
700707286
|
[1] |
HOSE
|
CAS
- Hydraulic
|
| 8. |
700708718
|
[2] |
TUBE,12.7 mm OD, 1527, 880 mm Length
|
CAS
Line - Hydraulic
|
| 9. |
791038
|
[3] |
ELBOW
|
CAS
90 Degree Elbow Superseded by part number: 241074
|
| 10. |
700118602
|
[5] |
STRAP
|
HFI
- Clamp, Line
|
| 11. |
700707269
|
[1] |
LINE
|
HFI
- Hydraulic
|
| 12. |
700708714
|
[1] |
HOSE ASSY.
|
CAS
Hose - Hydraulic
|
| 13. |
700118605
|
[2] |
STRAP
|
HFI
- Clamp, Line
|
| 14. |
700707270
|
[1] |
LINE
|
CAS
- Hydraulic
|
| . . |
703140
|
[2] |
BOLT,Hex, 1/4" - 20 x 1 3/4", Gr 5
|
CAS
1/4-20 x 1-3/4 C Superseded by part number: 413-428, 413-428, NLS
|
| . . |
7701485
|
[2] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
CAS
1/4-20 x 2 C Superseded by part number: 87404
|
| . . |
7706768
|
[4] |
5/16-18 x 1-1/4 C
|
DRIVE BUSHING,38.25mm ID x 47.74mm OD x 36.1mm L
|
| . . |
7701634
|
[2] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
3/8-16 x 2 C Superseded by part number: 88436
|
| . . |
704783
|
[4] |
SHIM,.020" Thk
|
NNA
1/4-20 HCLN Superseded by part number: 230-4214
|
| . . |
88902
|
[2] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
