凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (050) - MAINFRAME, TONGUE AND AXLE ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
432 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
26328
|
[12] |
BOLT,9/16" - 18 x 1.594", Grade 5
|
CAS
9/16-18 x 1-1/8 Wheel Bolt (S.N. CFH0015001 thru 0015766) Superseded by part number: 13542, 13542, T52730
|
| 1. |
826313
|
[12] |
NUT
|
CAS
9/16-18 Wheel Nut (S.N. CFH0015767 and on) Superseded by part number: G49041
|
| 2. |
700114344
|
[2] |
SCREW
|
CAS
- Special
|
| 3. |
704916
|
[2] |
SLOTTED NUT,5/8"-11, G5
|
CAS
5/8-11 Slotted Hex Nut Superseded by part number: 425-1210
|
| 4. |
300830
|
[2] |
SPACER
|
HFI
|
| 5. |
87415
|
[2] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
1/4-28 x 90 Degree Zerk
|
| 6. |
700116183
|
[1] |
TOW BAR
|
HFI
Tongue (Weldment) (S.N. CFH0015001 Thru 0016101)
|
| 6. |
700126776
|
[1] |
TOW BAR
|
HFI
Tongue (Weldment) (S.N. CFH0016102 and on)
|
| 7. |
700114239
|
[1] |
ARM
|
HFI
Support - Right (Weldment)
|
| 8. |
700118826
|
[2] |
SHIM
|
HFI
|
| 9. |
700117098
|
[2] |
CHANNEL
|
HFI
- Hinge
|
| 10. |
700114347
|
[1] |
SUPPORT
|
HFI
- Front
|
| 11. |
77040
|
[2] |
FITTING
|
CAS
1/4-28 x 45 Degree Zerk Superseded by part number: 219-90, 219-90, 87569
|
| 12. |
700114271
|
[1] |
SUPPORT
|
HFI
- Tailgate
|
| 13. |
700118603
|
[2] |
SUPPORT
|
HFI
|
| 14. |
700114238
|
[1] |
ARM
|
CAS
Support - Left (Weldment)
|
| . . |
702035
|
[7] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7883374
|
[8] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
7883382
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
704734
|
[28] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
