纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (10.102.03) - OIL LEVEL CHECK (504126782 - 504124642 - 504386780) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
253 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504124642 | [1] | DIPSTICK | TORASSY Contains Ref.1A, 2, 3 |
| 1A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 504027969 | [2] | SEALING RING | TORSEALRING |
| 4. | 5167640 | [2] | SEALING WASHER,14.09mm ID x 26.45mm OD x 1.5mm Thk | BAS |
| 5. | 504124643 | [1] | PIPE | TOR |
| 6. | 500349848 | [1] | CLAMP | TOR |
| 7. | 16992515 | [1] | PLUG | TOR |
| 8. | 16691324 | [2] | HEX SOC SCREW,M8 x 60mm | TOR |
| 9. | 14458681 | [1] | O-RING,1.487" ID x 0.103" Width | LEC |
| 10. | 2852136 | [1] | CAP | TOR |
| 11. | 16697821 | [1] | | SCREW |
| 12. | 17798674 | [1] | LOCK WASHER | ZED |
| 14. | 11903211 | [1] | PLUG,M12 x 1.25 x 12, Cl5.8 | TOR |
| 15. | 99489017 | [1] | GASKET,9.9mm ID x 20mm OD x 2.5mm Thk | TOR |
| 16. | 504256831 | [1] | OIL LEVEL | SENSOR |
