纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (10.103.01) - CRANKSHAFT & RELATED PARTS (504386695) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
531 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504388345 | [1] | ASSY Contains Ref,1A, 2, 3 | CRANKSHAFT |
| 1A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 2. | 99437423 | [1] | DRIVING GEAR | TOR |
| 3. | 10839610 | [1] | DOWEL,M8 x 12mm | TOR |
| 4. | 8097824 | [1] | RED | SET OF STD MAIN BRGS |
| 4. | 8097825 | [1] | GREEN | SET OF STD MAIN BRGS |
| 4. | 8097826 | [1] | RED BLACK | SET OF STD MAIN BRGS |
| 4. | 8097827 | [1] | GREEN BLACK | SET OF STD MAIN BRGS |
| 5. | 8097828 | [1] | STANDARD RED | SET OF THRUST WASHERS (STD) |
| 5. | 8097831 | [1] | STANDARD GREEN | SET OF THRUST WASHERS (STD) |
| 5. | 8097832 | [1] | RED BLACK | SET OF THRUST WASHERS (STD) |
| 5. | 8097833 | [1] | GREEN BLACK | SET OF THRUST WASHERS (STD) |
