凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (054) - SHIELDS, UPPER CENTER, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
607 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709195
|
[1] |
BUMPER
|
CAS
Chain (S.N. CFH0015275 and on)
|
| 2. |
700117068
|
[2] |
SUPPORT
|
HFI
|
| 3. |
700117050
|
[1] |
PANEL
|
HFI
- Vertical, Left
|
| 4. |
7025075
|
[4] |
BRACKET
|
CAS
- Hook
|
| 5. |
700116021
|
[1] |
SHIELD
|
CAS
- Front, Drive Shaft
|
| 6. |
700116008
|
[1] |
SHIELD
|
HFI
|
| 7. |
700707437
|
[1] |
COUNTER
|
CAS
- Bale
|
| 8. |
700117057
|
[1] |
PANEL
|
HFI
- Right
|
| 9. |
700116216
|
[1] |
SHIELD
|
HFI
- Right
|
| 10. |
700117102
|
[1] |
SHIELD
|
HFI
- Front, Upper
|
| 11. |
763557
|
[2] |
PIN
|
CAS
3/8 x 2-3/4 Clevis Pin Superseded by part number: Q657
|
| 12. |
700117096
|
[2] |
HINGE
|
CAS
- Shield, Top Superseded by part number: 700122785, 1703354, 113-52, 700122786
|
| 12. |
700122786
|
[2] |
HINGE
|
CAS
- Shield, Top
|
| 13. |
700117103
|
[1] |
SHIELD
|
CAS
- Top Superseded by part number: 700122810, 700122786
|
| 13. |
700122810
|
[1] |
SHIELD
|
CAS
- Top
|
| 14. |
700116215
|
[1] |
SHIELD
|
HFI
- Left
|
| . . |
700700992
|
[2] |
BOLT
|
CAS
1/4-20 x 6 C Superseded by part number: 413-496
|
| . . |
7701717
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5
|
CAS
5/16-18 x 1-1/2 C Superseded by part number: 88275
|
| . . |
700013
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7883325
|
[12] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883374
|
[32] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
700700628
|
[8] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
No. 10-24 x 1/2 CRPHMS Superseded by part number: 340-1108
|
| . . |
704072
|
[8] |
NUT
|
CAS
No. 10-24 H Superseded by part number: 225-14110, 225-14110, NLS
|
| . . |
1703354
|
[2] |
NUT
|
IH
1/4-20 HFTLN
|
