凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (058) - INDICATOR, BALE SIZE, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
961 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700115974
|
[1] |
SUPPORT
|
HFI
- Switch
|
| 2. |
700707234
|
[1] |
BUTTON
|
IH
Knob
|
| 3. |
700115976
|
[1] |
INDICATOR
|
HFI
|
| 4. |
700115973
|
[3] |
SPACER
|
CAS
|
| 5. |
700115983
|
[1] |
ANGLE
|
HFI
|
| 6. |
700115988
|
[1] |
LINK ASSY.
|
HFI
Link - Indicator
|
| 7. |
1713155
|
[1] |
FLAP
|
CAS
- Counter
|
| 8. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 Hardened Plain Washer
|
| 9. |
705525
|
[1] |
WASHER
|
CAS
5/16 Hardened Plain Washer Superseded by part number: 86637953
|
| 10. |
700115982
|
[1] |
SUPPORT
|
HFI
Arm (S.N. CFH0015001 thru 0015274)
|
| 11. |
700709602
|
[2] |
WASHER,5/16"
|
CAS
5/16 Wide Plain Washer Superseded by part number: 495-61034
|
| 12. |
6605174
|
[1] |
TUBE,19.05 mm OD, 35 mm Length
|
CAS
Spacer (S.N. CFH0015275 and on)
|
| . . |
703579
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 C
|
| . . |
7703945
|
[1] |
BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5
|
CAS
5/16-18 x 2-1/2 C Superseded by part number: 88346
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
7701188
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
| . . |
700013
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7883325
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
230-4215
|
[1] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
