神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-040) - OIL FILLER & OIL LEVEL GAUGE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
401 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME064440 | [1] | GAUGE | KOBCAGE GAUGE,OIL LEVEL |
| 2. | VAME070240 | [1] | GUIDE,OIL LEVEL | |
| 3. | VA3001305900 | [1] | GASKET | KOBGASKET Superseded by part number: 132394A1 |
| 4. | VAMF244878 | [2] | BOLT B0LT,W/WSR 10X20 | BOLT B0LT,W/WSR 10X20 |
| 5. | VAMF520005 | [1] | O-RING | KOB0-RING 10 Superseded by part number: 132399A1 |
| 6. | VAME930068 | [1] | STAY,OIL. LEVEL.GAUGE | |
| 7. | VAMB050032 | [1] | CLAMP | |
| 8. | VAMF140003 | [1] | BOLT | KOBBOLT,FLANGE 6X12 |
| 9. | VAMH000399 | [1] | SCREW | KOBBOLT,FLANGE 8X16 |
| 9A. | VAME920031 | [1] | SPACER L=28 | |
| 9B. | VAMF140234 | [1] | SPECIAL BOLT | KOBBOLT,FLANGE 8X45 |
| 20. | VAMH037755 | [1] | CAP,SEALING 13 | |
