神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-041) - OIL FILLER & OIL LEVEL GAUGE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
1000 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME064436 | [1] | OIL PRESSURE GAUGE | KOBGAUGE,OIL LEVEL |
| 2. | VAME039410 | [1] | GUIDE,OIL LEVEL | |
| 3. | VAMF520007 | [1] | O-RING | KOB0-RING 11 |
| 5. | VAMF520005 | [1] | O-RING | KOB0-RING 10 Superseded by part number: 132399A1 |
| 6. | VAME930223 | [1] | OIL LEVEL GAUGE STAY,OIL LEVEL GAUGE | OIL LEVEL GAUGE STAY,OIL LEVEL GAUGE |
| 8. | VAMF140003 | [1] | BOLT | KOBBOLT,FLANGE 6X12 |
| 20. | VAMH037755 | [1] | CAP,SEALING 13 | |
