神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-044) - AIR COMPRESSOR GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
220 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME037710 | [1] | AIR COMPRESSOR | KOBAIR COMPRESSOR ASSY 201CC |
| 3. | VAMF520423 | [1] | O-RING | KOBO-RING 135 Superseded by part number: VAF315313500 |
| 4. | VAMH000711 | [2] | SCREW | KOBBOLT,FLANGE 10X40 Superseded by part number: 135146A1 |
| 5. | VAMH000714 | [1] | BOLT | KOBBOLT,FLANGE 10X25 |
| 6. | VAMH000712 | [1] | SCREW | KOBBOLT,FLANGE 10X65 |
| 6A. | VAMF406292 | [1] | STUD 10X40 | |
| 6B. | VAMF406296 | [2] | BOLT | KOBSTUD 10X60 |
| . . | VAMF434105 | [2] | NUT | KOBNUT,FLANGE 10 |
| 7. | VAME037827 | [1] | PIPE,AIR SUCTION | |
| 8. | VA3117503901 | [1] | HOSE,RUBBER | |
| 9. | VAMS666012 | [2] | HOSE CLAMP | KOBCLAMP,HOSE 30 |
| 10. | VAME005073 | [1] | PIPE,BY-PASS | |
| 12. | VAMH005068 | [2] | WASHER | KOBWASHER,PLAIN |
| 15. | VA1614304702 | [1] | BOLT BOLT,UNION | BOLT BOLT,UNION |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 15A. | VA3117512101 | [1] | BRACKET BOLT,UNION | BRACKET BOLT,UNION |
| . . | VAMF660071 | [2] | PACKING | KOBGASKET 27 |
| 61-65. | VAMC802150 | [1] | GOVERNOR | KOBPRESSURE GOVERNOR ASSY A5 7.1-8.0 |
| 61. | NSS | [1] | NOT SOLD SEPARAT | CONBODY,PRESS. GOV |
| 62-65. | VAMC802151 | [1] | KIT, ENGINE TOP GASK | KOBPRESSURE GOVERNORKIT Superseded by part number: 77268813, VA4087070100 |
| 62. | VAME705602 | [1] | DIAPHRAGM | KOBDIAPHRAGM |
| 63. | VAMC821656 | [1] | O-RING | |
| 64. | VAME705601 | [1] | SLEEVE | |
| 65. | VAME705603 | [1] | CAP | |
