凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (052) - GUIDES, FORMING BELTS, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
472 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700122577
|
[2] |
GUIDE
|
CAS
- Belt (S.N. CFH0015767 and on) The Belt Guides will retrofit on all 8450 Round Balers
|
| 2. |
700122578
|
[2] |
GUIDE
|
CAS
Clamp - Half (S.N. CFH0015767 and on) The Belt Guides will retrofit on all 8450 Round Balers
|
| . . |
700054
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1/4 RHSNB Superseded by part number: 86508773
|
| . . |
704734
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
