凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (067) - ROLLER, FLAP, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
625 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707912
|
[4] |
FLAP
|
CAS
- Rubber (S.N. CFH0015001 thru 0015766)
|
| 1. |
700711998
|
[1] |
PAD, RUBBER
|
IH
Flap - Rubber (S.N. CFH0015767 and on)
|
| 2. |
700107940
|
[1] |
ROLLER
|
CAS
|
| 3. |
700117107
|
[4] |
BAND
|
IH
Strap - Reinforcement
|
| 4. |
700709141
|
[28] |
LOCK WASHER
|
CAS
Washer - Internal Lock Superseded by part number: 280542
|
| 5. |
700709140
|
[28] |
SELF-TAP SCREW,Pan HD, 5/16" - 18 x 3/4"
|
IH
5/16-18 x 3/4 CRTHTCTS
|
