纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (10.218.03) - FUEL LINES & RELATED PARTS (504386750) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
931 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504388755 | [1] | ASSY Contains Ref.1A, 28, 29 | INJECTION PIPE |
| 1A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 2. | 504384407 | [1] | | BRACKET, SUPPORTING |
| 3. | 2856035 | [2] | SCREW,Flng, M12 x 30mm, Cl 8.8 | TORM12 x 30 |
| 4. | 18139424 | [2] | SCREW,Hex, M10 x 20mm | TORM10 x 20 |
| 5. | 16673635 | [1] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TORM8 x 20 Superseded by part number: 16978124 |
| 6. | 504385780 | [1] | | BRACKET, SUPPORTING |
| 7. | 16586825 | [3] | BOLT,Hex, M8 x 1.25 x 45mm | TORM8 x 45 |
| 8. | 17044721 | [1] | NUT | ZED Superseded by part number: 2852389 |
| 9. | 504385798 | [1] | | BRACKET, SUPPORTING |
| 9. | 504388291 | [2] | | BRACKET, SUPPORTING |
| 10. | 504373497 | [1] | | INJECTION PIPE |
| 11. | 504373498 | [1] | | INJECTION PIPE |
| 12. | 504373512 | [1] | | INJECTION PIPE |
| 13. | 504373513 | [1] | | INJECTION PIPE |
| 14. | 504373514 | [1] | | INJECTION PIPE |
| 15. | 504373515 | [1] | | INJECTION PIPE |
| 16. | 504373516 | [1] | | INJECTION PIPE |
| 17. | 504373517 | [1] | | INJECTION PIPE |
| 18. | 504373531 | [2] | | FITTING |
| 19. | 16673735 | [4] | BOLT,Hex, M8 x 1.25 x 25mm | TORM8 x 25 Superseded by part number: 10278301 |
| 19. | 18137825 | [2] | BOLT,Hex, M6 x 16mm | TOR |
| 20. | 4858609 | [1] | O-RING | TTF |
| 21. | 98474308 | [1] | SEALING WASHER,16mm ID x 22mm OD x 1.5mm Thk | TOR |
| 22. | 504373643 | [1] | | BANJO BOLT |
| 23. | 504373532 | [1] | | BANJO BOLT |
| 24. | 504384719 | [1] | | INJECTION PIPE |
| 25. | 504373586 | [2] | | BRACKET, SUPPORTING |
| 26. | 504384385 | [1] | | INJECTION PIPE |
| 27. | 504384387 | [1] | | INJECTION PIPE |
| 28. | 504343022 | [1] | | SENSOR |
| 29. | 504347645 | [1] | | VALVE |
