凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (082) - BELTS, FORMING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
580 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707162
|
[4] |
BELT,177.00 mm W x 14484.02 mm L
|
CAS
Flat, Forming 177.00 mm W x 14484.02 mm L
|
| 2. |
700707160
|
[6] |
PIN,1.65mm OD x 195mm L
|
CAS
- Lacing, Solid Wire
|
| 2. |
700710206
|
[6] |
PIN,1.73mm OD x 180mm L
|
L
- lacing, cable
|
| 3. |
700707322
|
[12] |
LATCH ASSY.
|
L
Fastener
|
| 4. |
700708740
|
[2] |
BELT,165.00 mm W x 14541.5 mm L
|
CAS
Narrow 165.00 mm W x 14541.5 mm L
|
