卡特零件查询（725） 172-9973: LAMP GP-FLOOD
广数供应链运营团队, 14 02月, 2025，浏览：
687 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 228-6056 | [4] | SCREW(4-32X1.26-IN) | |
| 2. | 386-1294 | [1] | LENS AS(FLOODLIGHT) | |
| 3. | 107-5852 | [1] | SEAL | |
| 4. | 8T-4182M | [1] | BOLT(M10X1.5X45-MM) | |
| 5. | 351-9918 | [1] | LAMP-HALOGEN(24-VOLT, 70-WATT) | |
| 6. | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 7. | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| 8. | 8T-6912M | [1] | BOLT(M8X1.25X50-MM) | |
| 9. | 8T-7963M | [1] | LOCKNUT(M8X1.25-THD) | |
| 10. | 165-0699 | [1] | KIT-MOUNTING BRACKET(LAMP) | |
| | | | (INCLUDES BRACKET, BOLTS & LOCKNUT) |
| | | | |
| | 8T-4121F | [1] | WASHER-HARD(11X21X2.5-MM THK) | |
| | 8T-4133FM | [1] | NUT(M10X1.5-THD) | |
| | F | | NOT SHOWN |
| | M | | METRIC PART |
