凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (136) - KICKER EJECTOR, ELECTRICAL CONTROL ASSEMBLY, FRONT, S.N. CFH0015001 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
939 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
722470
|
[10] |
MOUNTING CLIP
|
CAS
Tie - Cable Superseded by part number: 529070
|
| 2. |
700709346
|
[1] |
HARNESS
|
CAS
- Wiring
|
| 3. |
86624005
|
[2] |
CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type
|
FOR
- Line
|
| 4. |
705699
|
[4] |
WASHER,#12
|
CAS
No. 12 Plain Washer Superseded by part number: 27616R1
|
| 5. |
700709344
|
[1] |
TERMINAL BOX
|
CAS
Box - Electronic
|
| 6. |
700119161
|
[1] |
SWITCH
|
L
- Normally Open
|
| 7. |
700707354
|
[1] |
CONNECTION,ELECTRIC
|
IH
Actuator Assembly
|
| 8. |
751487
|
[2] |
CLAMP
|
CAS
- Line Superseded by part number: 86632595
|
| 9. |
700709553
|
[1] |
RESISTOR
|
IH
|
| 10. |
700708090
|
[1] |
CLAMP
|
L
- Line Superseded by part number: 86637978
|
| 11. |
700708907
|
[1] |
VALVE
|
IH
- Ejector, Control
|
| 12. |
700118985
|
[1] |
MOUNTING PARTS
|
HFI
Mounting - Valve
|
| . . |
7703838
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 3/4", Gr 5
|
CAS
5/16-18 x 1-3/4 C Superseded by part number: 413-528, 413-528, NLS
|
| . . |
700707203
|
[4] |
CAPTIVE WASHER SCREW
|
CAS
No. 12-24 x 3/4 HWHMS
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883333
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 x 1 HWHMS Superseded by part number: 121-108
|
| . . |
7883374
|
[1] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 255918
|
| . . |
7774888
|
[4] |
NUT
|
CAS
No. 12-24 H Superseded by part number: 86512084
|
