纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (50.200.01) - COMPRESSOR, AIRCOND. (5801416964) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
525 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 16598325 | [4] | BOLT,Hex, M8 x 100mm | TORM8 X 100 |
| 2. | 17097024 | [2] | WASHER | TOR |
| 3. | 16692324 | [2] | BOLT | TORM10 X 35 |
| 3. | 504080093 | [2] | BOLT | TOR |
| 4. | 504078624 | [1] | BRACKET, SUPPORTING | TOR |
| 5. | 86993463 | [1] | AIRCOND. COMPRESSOR | GIASSY |
| 5. | 86993463R | [1] | REMAN-A/C COMPRESSOR | MKT |
| 5. | 86993463C | [1] | CORE-A/C COMPRESSOR | MKTReturn Number |
