纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (55.301.02) - ENGINE, ALTERNATOR MOUNTING (504386880) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
270 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 16598924 | [1] | SCREW,M10 x 110mm | TOR Superseded by part number: 16598925 |
| 2. | 504382197 | [1] | | SUPPORT |
| 3. | 98405462 | [2] | DOWEL | TOR |
| 4. | 16587425 | [2] | BOLT,M10 x 1.5 x 40mm | TORM10 x 120 |
| 5. | 87715398 | [1] | ALTERNATOR,12V, 200A | RAC |
| 5. | 87715398R | [1] | 12V, 200A | REMAN-ALTERNATOR |
| 5. | 87715398C | [1] | Return Number | CORE-ALTERNATOR |
| 7. | 2855573 | [1] | BOLT | TOR |
| 8. | 16600024 | [1] | BOLT,M12 x 160mm | TOR |
| 9. | 504080582 | [1] | SPACER | TOR |
| 10. | 86625255 | [1] | WASHER,13.3mm ID x 24.5mm OD x 3mm Thk | GI |
| 11. | 337475 | [1] | NUT,M12, Cl 10 | BHB |
