神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (08-002) - CYLINDER BLOCK REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-27. | VAME999548 | [1] | CRANKCASE ASSY 6D16,16T | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP.BRG FR I MI |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCAP,BRG RE |
| 4. | VAME031865 | [14] | SCREW | KOBBOLT 14X108 |
| 5. | VAME041105 | [6] | LINER, ENGINE CYLIND | KOBLINER,CYL B SIZE 1 |
| 5. | VAME041106 | [6] | LINER, ENGINE CYLIND | KOBLINER,B SIZE 2 |
| 5. | VAME041107 | [6] | LINER, ENGINE CYLIND | KOBLINER,B SIZE 3 |
| 8. | VAMH012041 | [6] | PIN | KOBPIN,SPG 4X10 |
| 9. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| 9. | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 10A. | VAME041108 | [5] | CAP | KOBCAP,SEALING 50 |
| 10B. | VAMH037754 | [1] | CAP | KOBCAP,SEALING 50 |
| I0C. | VAMS666139 | [9] | CAP | KOBCAP,SEALING 30 |
| 10D. | VAMS666142 | [1] | CAP | KOBCAP,SEALING 45 |
| 11. | VAMH012024 | [2] | PIN | KOBPIN,SPG 10X20 |
| 12. | VAMH007011 | [1] | PIN | KOBPIN,DOWEL 12X34 Superseded by part number: 132324A1 |
| 13. | VAMF665535 | [1] | CAP | KOBCAP,SEALING 18 |
| 14. | VAMH007010 | [1] | PIN | KOBPIN,DOWEL 12X17 |
| 15. | VAMF472404 | [2] | DOWEL | KOBPIN,DOWEL 8X18 Superseded by part number: MF472404 |
| 16. | VAMH037082 | [2] | PLUG PLUG 6.5X8 | PLUG PLUG 6.5X8 |
| 17. | VAME031042 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.1 |
| 18. | VAME031043 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.2 |
| 19. | VAME031044 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.3 |
| 20. | VAME031096 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.4 |
| 21. | VAME031087 | [3] | SET OF SCREWS | KOBSCREW,SET |
| 21. | VAMF660063 | [3] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 21A. | VAME031087 | [1] | SET OF SCREWS | KOBSCREW,SET |
| 21A. | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 22. | VAME031099 | [2] | PIN | KOBPIN,DOWEL,OIL PUMP |
| 23. | VAME031058 | [1] | CAP | KOBCAP,SEALING 64 |
| 24. | VAME031088 | [2] | PLUG | KOBPLUG |
| 24. | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 25. | VAMS666222 | [1] | PLUG | SMPLUG,TAPER PT3/8 |
| 27. | VAMH037755 | [1] | CAP,SEALING 13 | |
