神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (08-003) - CYLINDER HEAD REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
144 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-13. | VAME999455 | [1] | HEAD ASSY CYLINDER HEAD ASSY 6Dl4T,15T,FOR M1 ONLY | HEAD ASSY CYLINDER HEAD ASSY 6Dl4T,15T,FOR M1 ONLY |
| 1-13. | VAME999453 | [1] | HEAD ASSY CYLINDER CYLINDER HEAD ASSY,6D15,FOR M2 ONLY | HEAD ASSY CYLINDER CYLINDER HEAD ASSY,6D15,FOR M2 ONLY |
| 1-13. | VAME999547 | [1] | CYLINDER HEAD | KOBCYLINDER HEAD ASSY,6D16T,FOR M6 ONLY Superseded by part number: VAME997381 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHEAD,CYL,FOR M1 ONLY |
| 2. | VAME031931 | [6] | INSERT | KOBINSERT,VALVE SEAT INLET,FOR M1 ONLY |
| 2. | VAME031929 | [6] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE INSERT,VALVE SEAT INLET,FOR M2 ONLY Superseded by part number: VAME071002 |
| 2. | VAME041130 | [6] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE INSERT,VALVE SEAT INLET,FOR M6 ONLY |
| 3. | VAME031935 | [6] | INLET MANIFOLD | KOBINSERT,VALVE SEAT EXH,FOR M1,M6 ONLY |
| 3. | VAME031933 | [6] | VALVE | KOBINSERT,VALVE SEAT EXH,FOR M2 ONLY Superseded by part number: VAME031934 |
| 4. | VAME031886 | [6] | GUIDE | KOBGUIDE,VALVE INLET |
| 5. | VAME031888 | [6] | GUIDE | KOBGUIDE,VALVE EXH |
| 6. | VAMS666137 | [18] | CAP | KOBCAP,SEALING 25 |
| 7. | VAMS666136 | [5] | PLUG | KOBCAP,SEALING 22 |
| 8. | VAMH002111 | [1] | STUD | KOBSTUD 8X20 |
| 9. | VAMH002169 | [12] | STUD | KOBSTUD 10X33 Superseded by part number: VAMH002175 |
| 10. | VAME030855 | [6] | TUBE | KOBTUBE,NOZZLE,FOR M1,M2 ONLY |
| 11. | VAMH035157 | [6] | O-RING | KOBO-RING.TUBE Superseded by part number: 132299A1 |
| 13. | VAMH004054 | [12] | NUT | KOBFLANGE 10 Superseded by part number: 134868A1 |
