纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.106.01) - CAMSHAFT (504386720) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
992 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504384173 | [1] | | CAMSHAFT |
| 2. | 504369842 | [1] | | GEAR |
| 3. | 98496024 | [1] | SPACER | TOR |
| 4. | 99431774 | [4] | BOLT | TOR |
| 5. | 504374044 | [1] | | PLATE |
| 6. | 504367230 | [4] | SCREW | TORM8X1.25X25 |
| 7. | 504204255 | [1] | COVER | TOR |
| 8. | 14465381 | [1] | O-RING,3.109" ID x 3.387" OD x 0.139" | MKT Superseded by part number: 17290781 |
| 9. | 18139424 | [4] | SCREW,Hex, M10 x 20mm | TORM10 x 25 |
