纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.106.02) - SHAFT & ROCKER ARMS (504386670) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
892 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 16988301 | [1] | PLUG | TOR |
| 2. | 504303856 | [1] | | ROCKSHAFT |
| 2A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 504368817 | [6] | EXHAUST ASSY Contains Ref.4, 5, 6, 7, 8 | ROCKER ARM |
| 5. | 98498411 | [12] | SCREW | TOR |
| 6. | 504059553 | [12] | NUT | AST |
| 7. | 17084376 | [12] | RING | TOR |
| 8. | 500300903 | [12] | SLIDING PAD | TOR |
| 11. | 504368823 | [6] | | LEVER |
| 12. | 500344277 | [7] | CAP | TORASSY |
| 13. | 99475580 | [7] | SCREW | TOR |
