神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-003) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
883 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME038929 | [1] | INJECTION PUMP GENERAL ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY A TYPE |
| 2. | VAME032815 | [1] | GOVERNOR ASSY RSV TYPE | |
| 3. | VAME717109 | [1] | PUMP | KOBFUEL FEED PUMP ASSY KE TYPE |
| 4. | VAME032899 | [1] | AUTOMATIC T AUTOMATIC TIMER ASSY SBZ TYPE | AUTOMATIC T AUTOMATIC TIMER ASSY SBZ TYPE |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DISK,DRIVING Superseded by part number: VAME076553 |
| 8. | VAMF520421 | [1] | O-RING | KOBO-RING 125 |
| 9. | VAME035906 | [1] | STAY,I/P | |
| 10. | VAMF140223 | [2] | BOLT | KOBBOLT,FLANGE 8X16 |
| 14. | VAMF434105 | [4] | NUT | KOBNUT,FLANGE 10 |
| 15. | VAMF434105 | [1] | NUT | KOBNUT,FLANGE 10 |
| 18. | VAME039298 | [1] | LEVER LEVER,GOV | LEVER LEVER,GOV |
| 19. | VAMF241229 | [2] | BOLT | KOBBOLT.W/WSR 6X25 |
| 20. | VAMH037116 | [1] | FLEXIBLE JOINT | KOBJOINT,SWIVELING 10 |
| 24. | VAMH005061 | [2] | WASHER T=1 | |
| 25. | VAMH032777 | [1] | HOSE,FLEX. | |
| 26. | VAMH037279 | [1] | BOLT | KOBBOLT,EYE 10X20 P = 1.5 |
| 27. | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
