斗山零件查询INTAKE MANIFOLD DX160LC-3 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
557 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
240203-00016A
|
[1] |
|
|
| 10. |
06.01923-3125
|
[4] |
. BOLT ASS`Y M8X70
|
|
| 11. |
110449-00014
|
[1] |
|
|
| 12. |
06.01923-3114
|
[1] |
BOLT ASS`Y M8X22
|
|
| 13. |
06.01923-3218
|
[2] |
BOLT ASS`Y M10X35
|
|
| 14. |
301318-00007
|
[1] |
|
|
| 15. |
06.01923-2913
|
[1] |
BOLT ASS`Y M6X20
|
|
| 16. |
65.08204-0004A
|
[1] |
COVER
|
|
| 17. |
06.01913-2910
|
[2] |
. BOLT;HEX. M6X12
|
|
| 18. |
410139-00010A
|
[1] |
|
|
| 19. |
120106-00349
|
[4] |
|
|
| 2. |
65.08902-0030A
|
[2] |
GASKET;MANIFOLD
|
|
| 20. |
65.90201-0111
|
[1] |
|
|
| 21. |
65.90701-0087
|
[1] |
WASHER
|
|
| 22. |
06.16731-2107
|
[2] |
WASHER
|
|
| 23. |
06.15010-2311
|
[1] |
WASHER
|
|
| 24. |
06.11063-8214
|
[1] |
. NUT
|
|
| 3. |
06.01923-3218
|
[12] |
BOLT ASS`Y M10X35
|
|
| 4. |
240401-00025B
|
[1] |
|
|
| 4. |
240401-00025A
|
[1] |
|
|
| 5. |
65.09904-0008
|
[1] |
GASKET;AIR HEATER
|
|
| 6. |
06.01923-3117
|
[3] |
. BOLT ASS`Y M8X30
|
|
| 7. |
65.09904-0008
|
[2] |
GASKET;AIR HEATER
|
|
| 8. |
65.26803-7028B
|
[1] |
AIR HEATER
|
|
| 9. |
240401-00011
|
[1] |
|
|
