纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.102.02) - CRANKCASE COVERS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855172 | [1] | HOUSING | TOR |
| 2. | 4890833 | [1] | OIL SEAL,M130 x 155 x 12.5/16 | TOR Superseded by part number: |
| 3. | 4899145 | [2] | BOLT,Flng, M12 x 1.75 x 100mm | TOR |
| 4. | 4891250 | [15] | BOLT,Flng, M12 x 1.75 x 78mm, Cl 10.9 | TOR |
| 4. | 4899385 | [1] | FLANGE BOLT,Hex, M16 x 1.5 x 80mm, Cl 8.8 | TOR |
| 5. | 4895586 | [2] | SCREW,Hex, Flg Hd, M8 x 16 | TOR |
| 6. | 4894532 | [2] | DOWEL,M18 x 10 L | TOR |
| 7. | 4895392 | [1] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY |
| 8. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 9. | 2854809 | [1] | COVER | TORASSY |
| 10. | 2853695 | [1] | O-RING | TOR Superseded by part number: 504108486 |
