纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.106.02) - ROCKER SHAFT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895432 | [5] | SCREW | TORM8 x 1,25 x 70 |
| 2. | 2859460 | [6] | ROCKER ARM | TORASSY |
| 3. | 4897248 | [2] | RETAINER | TOR Superseded by part number: |
| 4. | 4897245 | [2] | SOCKET | TOR Superseded by part number: |
| 5. | 2859462 | [1] | ROCKER ARM | TORASSY |
| 6. | 2859467 | [2] | NUT | TOR Superseded by part number: |
| 7. | 2859468 | [2] | ADJUSTMENT SCREW,3/8" - 24 x 23.85mm | TOR |
| 8. | 2859470 | [2] | SOCKET | TOR |
| 9. | 2852776 | [3] | WASHER | TOR Superseded by part number: 4895421 |
| 10. | 2852428 | [6] | WIRE CLAMP,6mm ID | TOR Superseded by part number: 504066132 |
| 11. | 2859461 | [1] | ROCKER ARM | TORASSY |
| 12. | 4899245 | [5] | SLEEVE | TOR |
| 13. | 4899257 | [1] | HOUSING | TORASSY |
| 14. | 2852427 | [3] | WIRE HARNESS | TOR Superseded by part number: 47401109 |
| 15. | 2856460 | [2] | BOLT,Flng, M8 x 1.25 x 55.5mm, Cl 10.9 | TOR |
| 16. | 2859463 | [1] | SUPPORT | TOR Superseded by part number: |
| 17. | 4895031 | [12] | PUSH ROD | TOR |
| 18. | 2854530 | [12] | BRIDGE | SM |
| 19. | 2853788 | [1] | GASKET,10.35mm Thk | TOR Superseded by part number: 504070040 |
| 20. | 2852602 | [3] | HEX SOC SCREW,M6 x 16mm | SM Superseded by part number: 16689121 |
| 21. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
