沃尔沃零件查询AD30A; AQAD30A; MD30A; TAMD30A; TMD30A; AD30; AQAD30; MD30; TAMD30; TMD30EngineTiming Gear Casing and GearsEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
884 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
842988
|
[1] |
Timing gear casing
|
|
| 2. |
415311
|
[1] |
Guide sleeve
|
|
| 3. |
1542219
|
[1] |
Gasket
|
|
| 4. |
941907
|
[4] |
Spring washer
|
|
| 5. |
955295
|
[3] |
Hexagon screw
|
L=20mm
|
| 5. |
940142
|
[1] |
Hexagon screw
|
L=30mm
|
| 6. |
1542305
|
[1] |
Gear
|
|
| 7. |
1542061
|
[1] |
Gear
|
|
| 8. |
838997
|
[1] |
Bearing spindle
|
(1542064)
|
| 9. |
1542065
|
[1] |
Thrust washer
|
|
| 10. |
965180
|
[3] |
Flange screw
|
|
| 11. |
1542034
|
[1] |
Gear
|
|
| 12. |
1542223
|
[1] |
Washer
|
|
| 13. |
955344
|
[1] |
Hexagon screw
|
|
| 14. |
1544149
|
[1] |
Gear
|
|
| 15. |
829523
|
[1] |
Companion flange
|
|
| 16. |
955299
|
[4] |
Hexagon screw
|
|
| 17. |
941907
|
[4] |
Spring washer
|
|
| 18. |
1542171
|
[1] |
Hub
|
See group 2C
|
| 19. |
1542215
|
[1] |
Oil pump wheel
|
|
| 20. |
843086
|
[1] |
Cover
|
Replaced by 842991
|
| 20. |
842991
|
[1] |
Cover
|
|
| 21. |
1542318
|
[1] |
Sealing ring
|
|
| 22. |
415311
|
[2] |
Guide sleeve
|
|
| 23. |
859038
|
[1] |
Gasket
|
(842990)
|
| 24. |
941907
|
[13] |
Spring washer
|
|
| 25. |
940132
|
[7] |
Hexagon screw
|
L=35mm
|
| 25. |
955301
|
[2] |
Hexagon screw
|
L=55mm, see group 2C
|
| 26. |
955304
|
[6] |
Hexagon screw
|
L=70mm
|
| 26. |
955307
|
[3] |
Hexagon screw
|
L=100mm, see group 3
|
| 26. |
955306
|
[1] |
Hexagon screw
|
L=80mm, see group 3
|
