纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.304.01) - OIL PUMP New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
185 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831401 | [1] | ENGINE OIL PUMP | TOR |
| 1. | 2830914R | [1] | REMAN-ENG OIL PUMP | TORPlease see Attached Service Bulletin |
| 1. | 2830914C | [1] | CORE PUMP, ENGINE OIL | TORReturn Number |
| 2. | 2830972 | [1] | GASKET,2.3mm Thk | TOR |
| 3. | 4890832 | [1] | OIL SEAL,M70 x 100 x 12.5/16 | TOR Superseded by part number: |
| 4. | 4899019 | [11] | SCREW,Hex Flg, M8 x 1.25 x 35 | TOR |
| 4. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
| 4. | 4899031 | [2] | BOLT,Flng, M8 x 1.25 x 25mm | TOR Superseded by part number: 4899079 |
