纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.400.01[02]) - ENGINE COOLING SYSTEM PIPING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
367 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY |
| 2. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 3. | 2854491 | [1] | PLUG,Taper Pipe, Hex, 1/4" - 18 x 14.224mm | TOR |
| 4. | 4895078 | [4] | PIPE PLUG,1/2"-14 | TORASSY |
| 5. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 6. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY |
| 7. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 8. | 4895392 | [1] | HEX SOCKET PLUG,M18 x 1.5 | TOR |
