沃尔沃零件查询861 Large-volume horn 98973 (6282)861 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
449 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE955525
|
[0002] |
Hexagon screw
|
|
| 6. |
VOE13955894
|
[0002] |
Washer
|
|
| 7. |
VOE950353
|
[0002] |
Lock nut
|
|
| 8. |
VOE955137
|
[0004] |
Cross recessed screw
|
|
| 9. |
|
[0002] |
Bracket
|
|
| 1. |
VOE1507842
|
[0002] |
Air Horn
|
|
| 10. |
VOE13945460
|
[REQ] |
Plastic pipe
|
|
| 11. |
VOE13945460
|
[REQ] |
Plastic pipe
|
|
| 12. |
VOE954356
|
[0002] |
Fitting nut
|
|
| 13. |
VOE954364
|
[0002] |
Ferrule
|
|
| 14. |
VOE944717
|
[0002] |
Sleeve
|
|
| 15. |
VOE192258
|
[0002] |
Nipple
|
|
| 16. |
VOE6626874
|
[0001] |
Clutch
|
|
| 17. |
VOE13945460
|
[REQ] |
Plastic pipe
|
|
| 18. |
VOE6626949
|
[0001] |
Solenoid valve
|
|
| |
VOE273308
|
[0001] |
Repair kit
|
|
| 2. |
VOE1580257
|
[0002] |
Protection
|
|
| 19. |
|
[0001] |
Valve plate
|
SEE GROUP 41
|
| 20. |
VOE6626873
|
[1] |
Fitting
|
|
| |
VOE957175
|
[2] |
Gasket
|
|
| 21. |
VOE951188
|
[0012] |
Clamp
|
|
| 22. |
VOE955119
|
[0012] |
Cross recessed screw
|
|
| 3. |
VOE1505143
|
[0002] |
Gasket
|
|
| 4. |
VOE955896
|
[0002] |
Plain washer
|
|
