斗山零件查询OIL COOLER PIPING(1) DX160LC-3 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
178 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-05724
|
[-] |
|
|
| 101. |
2181-1950D7
|
[1] |
. PLUG
|
|
| 102. |
2181-1950D15
|
[1] |
PLUG
|
|
| 103. |
S8000181
|
[1] |
O-RING
|
|
| 104. |
S8000231
|
[1] |
O-RING
|
|
| 14. |
2185-1002D93
|
[1] |
HOSE
|
|
| 16. |
S8500105
|
[4] |
CLAMP
|
|
| 17. |
DS2023692
|
[1] |
HOSE ASSY
|
|
| 19. |
DS2013159
|
[1] |
HOSE
|
|
| 22. |
DS2012150
|
[1] |
|
|
| 25. |
DS2232232
|
[1] |
ADAPTER
|
|
| 28. |
2181-2294D1
|
[1] |
ELBOW
|
|
| 29. |
2181-4133D38
|
[1] |
ADAPTER
|
|
| 31. |
DS2412022
|
[1] |
TEE
|
|
| 37. |
S2215366
|
[4] |
BOLT
|
|
| 40. |
S8000141
|
[1] |
O-RING
|
|
| 41. |
S8000181
|
[1] |
O-RING
|
|
| 42. |
S8000231
|
[2] |
O-RING
|
|
| 43. |
S8030081
|
[3] |
O-RING
|
|
| 44. |
S8030121
|
[2] |
O-RING
|
|
| 45. |
S8030161
|
[2] |
O-RING
|
|
| 50. |
2180-1026D31
|
[1] |
O-RING
|
|
| 52. |
DS2291011
|
[1] |
ELBOW
|
|
| 7. |
420218-00091B
|
[1] |
|
|
