斗山零件查询SEAT SLIDING PLATE DX160LC-3 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
625 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
250110-00054E
|
[-] |
|
|
| 1. |
250110-00055A
|
[1] |
|
|
| 10. |
S4214603
|
[4] |
NUT;CASTLE M10X1.5
|
|
| 11. |
S5735371
|
[4] |
PIN;SPLIT
|
|
| 12. |
100202-00003B
|
[2] |
|
|
| 13. |
110406-00414
|
[2] |
|
|
| 14. |
110406-00415
|
[2] |
|
|
| 15. |
120810-00050
|
[8] |
|
|
| 16. |
2121-1311D2
|
[4] |
NUT
|
|
| 17. |
440-00237A
|
[2] |
SPRING;GAS
|
|
| 18. |
250201-00363
|
[2] |
|
|
| 19. |
2120-2166D5
|
[8] |
BOLT
|
|
| 2. |
110431-00029C
|
[1] |
|
|
| 20. |
2114-1898D14
|
[20] |
WASHER
|
|
| 21. |
2120-2166D30
|
[4] |
BOLT M8X1.25X30
|
|
| 22. |
220204-00156A
|
[1] |
|
|
| 22A. |
101544-00032A
|
[1] |
|
|
| 23. |
220204-00145B
|
[1] |
|
|
| 24. |
220204-00146B
|
[1] |
|
|
| 26. |
S3456813
|
[2] |
SCREW
|
|
| 27. |
2120-2166D57
|
[4] |
BOLT
|
|
| 28. |
K1002385
|
[2] |
STOPPER
|
|
| 29. |
2114-2031D4
|
[8] |
WASHER
|
|
| 3. |
110431-00030C
|
[1] |
|
|
| 4. |
120501-00160C
|
[2] |
|
|
| 5. |
2114-1898D18
|
[2] |
WASHER
|
|
| 6. |
114-00590
|
[2] |
WASHER
|
|
| 7. |
120810-00047
|
[2] |
|
|
| 8. |
110920-00007
|
[2] |
|
|
| 9. |
2114-1058D63
|
[2] |
WASHER
|
|
