| 1. |
433-836
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2 1/4", Gr 5
|
CAS
1/2-13 X 2-1/4 RHSNB Superseded by part number: 280504
|
| 2. |
231-5148
|
[18] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 3. |
434-616
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 4. |
231-5146
|
[6] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 5. |
433-816
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 6. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 7. |
700131945
|
[2] |
STRAP
|
HFI
|
| 8. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
BEARING ASSEMBLY (Includes item 11)
|
| 9. |
50468
|
[2] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 22, 43.66 mm
|
IH
- spherical
|
| 10. |
663562R1
|
[4] |
FLANGE
|
IH
- bearing
|
| 11. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 12. |
700131959
|
[1] |
SUPPORT
|
HFI
- left, lower
|
| 13. |
700100054
|
[4] |
SPACER
|
CAS
|
| 14. |
700126902
|
[8] |
SPACER
|
HFI
|
| 15. |
700124601
|
[2] |
RING
|
HFI
WA - grass
|
| 16. |
433-828
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 17. |
700122771
|
[2] |
SPACER
|
IH
RING - grass
|
| 18. |
700126907
|
[1] |
MOUNTING PARTS
|
CAS
ROLLER ASSEMBLY (Includes item 33)
|
| 19. |
8050825
|
[2] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 20. |
700116217
|
[1] |
ROLL
|
IH
ER ASSEMBLY (Includes item 19)
|
| 21. |
51318
|
[1] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| 22. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY (Includes item 21)
|
| 23. |
433-620
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 24. |
700122715
|
[1] |
SUPPORT
|
HFI
- right, lower (S.N. CFH0080001 thru CFH0080405)
|
| . . |
700133269
|
[1] |
SUPPORT
|
HFI
WA - right, lower (S.N. CFH0080406 and later)
|
| 25. |
413-1228
|
[2] |
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
|
CAS
3/4-10 x 1-3/4 C Superseded by part number: 88725
|
| 26. |
492-11075
|
[2] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 27. |
495-21081
|
[2] |
WASHER,3/4"
|
CAS
Superseded by part number: 86511191
|
| 28. |
413-816
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
CAS
Superseded by part number: 87909, BN50282
|
| 29. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 30. |
700100927
|
[2] |
HUB
|
L
|
| 31. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 32. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 33. |
700133284
|
[1] |
CRANK
|
IH
ROD - guide
|
| 34. |
700128343
|
[2] |
BAND
|
IH
STRAP
|
