| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700107940
|
[1] |
ROLLER
|
CAS
WA
|
| 2. |
700711998
|
[4] |
PAD, RUBBER
|
IH
FLAP - rubber
|
| 3. |
493-81008
|
[28] |
LOCK WASHER,Int Tooth, 5/16"
|
CAS
WASHER - internal tooth lock, 5/16 inch Superseded by part number: 280542
|
| 4. |
700709140
|
[28] |
SELF-TAP SCREW,Pan HD, 5/16" - 18 x 3/4"
|
IH
5/16-18 X 3/4 CRTHTCTS
|
| 5. |
700117107
|
[4] |
BAND
|
IH
STRAP
|
