凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-40) - MESH WRAP ADAPTER KIT, HK50596 MESH WRAP ADAPTER KIT COMPLETE, S.N. CFH0073011 THROUGH CFH0073271 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-40) - MESH WRAP ADAPTER KIT, HK50596 MESH WRAP ADAPTER KIT COMPLETE, S.N. CFH0073011 THROUGH CFH0073271 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 676 次

Pos.	Part No	Qty	Parts name	Comments
. .	HK50596	[1]	MESH WRAP ADAPTER KIT COMPLETE
1.	237-6004	[7]	O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro	CAS 4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
2.	218-5103	[1]	90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB	CAS 90 DEGREE ELBOW (Includes item 1) Superseded by part number: 216773
3.	7792500	[6]	ELBOW	CAS 90 DEGREE ELBOW (Includes item 1) Superseded by part number: 165202, 216773
4.	700711967	[1]	VALVE	CAS - control
5.	413-428	[2]	BOLT,Hex, 1/4" - 20 x 1-3/4", Gr 5	CAS .25 X 1.75 UNC GR5 YZD Superseded by part number: 280164
6.	231-5144	[2]	SERRATED NUT,Flg, USR, 1/4"-20	CAS Superseded by part number: 523282, 72187066
7.	700711082	[1]	HYDRAULIC HOSE,6.35 mm ID x 270.00 mm, SAE 100R1	CAS 6.35 mm ID x 270.00 mm, SAE 100R1
8.	700711007	[1]	HYDRAULIC HOSE,6.35 mm ID x 5400.00 mm, SAE 100R1	CAS 6.35 mm ID x 5400.00 mm, SAE 100R1
9.	700128332	[1]	SUPPORT	HFI - switch
10.	L18337	[5]	CABLE TIE,9.95"-12.1" lg	CAS STRAP - tie, 15 inch, nylon Superseded by part number: 529070
11.	121-115	[2]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
12.	231-5145	[5]	SERRATED NUT,Flg, USR, 5/16"-18	CAS NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
13.	700711008	[1]	HYDRAULIC HOSE,6.35 mm ID x 6600.00 mm, SAE 100R1	CAS 6.35 mm ID x 6600.00 mm, SAE 100R1
14.	413-516	[3]	BOLT,Hex, 5/16" - 18 x 1", Gr 5	CAS C Hex, 5/16"-18 x 1", G5, Full Thd Superseded by part number: 9635884, 72187198
15.	515-23190	[6]	CLAMP,3/4", Insul, 3/8" Bolt	CAS Hose 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
16.	700711009	[1]	HYDRAULIC HOSE,6.35 mm ID x 1850.00 mm, SAE 100R1	CAS 6.35 mm ID x 1850.00 mm, SAE 100R1
17.	121-226	[1]	SERRATED BOLT,Hex, 3/8" - 16 x 1"	CAS Superseded by part number: 87034804
18.	231-5146	[1]	FLANGE NUT,3/8"-16	CAS Superseded by part number: 72187068, 247780
19.	515-23254	[6]	CLAMP,1", Insul, 3/8" Bolt	CAS Hose 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
20.	700701355	[1]	3 WAY CONNECTION	CAS TEE Superseded by part number: 86513653
21.	700130845	[1]	GUIDE	HFI
22.	425-108	[1]	NUT,1/2" - 13, Gr 5	CAS NUT, 1/2"-13, G5 Superseded by part number: 280431
