凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-42) - MESH WRAP ADAPTER KIT, HK50904 MESH WRAP ADAPTER KIT COMPLETE, SERIAL NUMBER CFH0073272 AND LATER Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-42) - MESH WRAP ADAPTER KIT, HK50904 MESH WRAP ADAPTER KIT COMPLETE, SERIAL NUMBER CFH0073272 AND LATER Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 381 次

Pos.	Part No	Qty	Parts name	Comments
. .	HK50904	[1]	MESH WRAP ADAPTER KIT COMPLETE
1.	700715899	[1]	HOSE	CAS - hydraulic
2.	L18337	[10]	CABLE TIE,9.95"-12.1" lg	CAS STRAP - tie, 15 inch, nylon Superseded by part number: 529070
3.	700711082	[1]	HYDRAULIC HOSE,6.35 mm ID x 270.00 mm, SAE 100R1	CAS 6.35 mm ID x 270.00 mm, SAE 100R1
4.	218-5103	[1]	90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB	CAS - 90 degrees (Includes item 22) Superseded by part number: 216773
5.	7792500	[3]	ELBOW	CAS - 90 degrees (Includes item 22) Superseded by part number: 165202, 216773
6.	413-428	[2]	BOLT,Hex, 1/4" - 20 x 1-3/4", Gr 5	CAS .25 X 1.75 UNC GR5 YZD Superseded by part number: 280164
7.	1703354	[2]	NUT	IH 1/4-20 HFTLN GR/G
8.	700711967	[1]	VALVE	CAS ASSEMBLY - control (Supplied with mesh wrap kit only)
9.	218-5222	[1]	TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run	CAS service 37º, 9/16"-18, x 9/16"-18, Fem Sw Run Superseded by part number: 72186135, 129274
10.	700715895	[1]	REDUCER	CAS 9/16 X 7/16 JIC ADAPTER
11.	700707498	[1]	ELBOW	CAS 7/16 X 9/16 X 90 DEGREE ELBOW (Includes item 22)
12.	700128332	[1]	SUPPORT	HFI - switch
13.	121-115	[2]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
14.	232-5315	[2]	FLANGE NUT,Flg, 5/16"-18	CAS 5/16-18 HFTLN GR/G
15.	700711007	[1]	HYDRAULIC HOSE,6.35 mm ID x 5400.00 mm, SAE 100R1	CAS 6.35 mm ID x 5400.00 mm, SAE 100R1
16.	700130845	[1]	GUIDE	HFI
17.	231-5348	[1]	FLANGE NUT,Flg, 1/2"-13	CAS 1/2-13 HFTLN GR/G Superseded by part number: 86521610
18.	121-226	[1]	SERRATED BOLT,Hex, 3/8" - 16 x 1"	CAS Superseded by part number: 87034804
19.	232-5316	[1]	FLANGE NUT,Flg, 3/8"-16	CAS 3/8-16 HFTLN GR/G Superseded by part number: 86521609
20.	515-23254	[6]	CLAMP,1", Insul, 3/8" Bolt	CAS Hose 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
21.	700711008	[1]	HYDRAULIC HOSE,6.35 mm ID x 6600.00 mm, SAE 100R1	CAS 6.35 mm ID x 6600.00 mm, SAE 100R1
22.	237-6004	[5]	O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro	CAS 4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
